34470A 數字萬用表以無與倫比的顯示方式，幫助工程師多層次觀察測量結果、快速獲得有效信息、輕松歸檔測量結果。Truevolt 數字萬用表提供趨勢圖、直方圖等高級圖形顯示功能，有助于工程師更快速地獲得深入分析。34470A 數字萬用表提供三種采集模式.

表 主要特性與技術指標

?Resolutions up to 7? digits
?Reading rates up to 50,000 readings/s
?Memory up to 2 million readings
?Voltage ranges from 100 mV to 1,000 V
?Current ranges from 1 μA to 10 A
?USB and LAN interfaces, optional GPIB
?BenchVue software enabled

34470A 7位半數字萬用表 描述

The Keysight 34470A 7? digit, Performance Truevolt DMMs offer higher levels of accuracy, speed and resolution.

Get more insight quickly: Truevolt DMM's graphical capabilities such as trend and histogram charts offer more insights quickly. Both models also provide a data logging mode for easier trend analysis and a digitizing mode for capturing transients.

Measure low-power devices: The ability to measure very low current, 1 μA range with
pA resolution, allows you to make measurements on very low power devices.

Maintain calibrated measurements: Auto calibration allows you to compensate for temperature drift so you can maintain measurement accuracy throughout your workday.
